TEACHING AND COLLABORATION MADE EASY
Features and Capabilities
Access the Promethean Menu by selecting the Flame button on the console/remote, or by clicking the designated on-screen area.
More about Promethean MenuUse your fingertips or Promethean pens to experience Vellum touch technology and simultaneous touchpoint capabilities.
The ActivPanel comes with a wide range of pre-installed applications that can be accessed instantly.
Promethean ActivPanels are equipped with an infinite whiteboard canvas. Draw and write freely without running out of space.
Wirelessly share and interact with content from up to 4 devices at a time for increased collaboration.
Easily and conveniently log in to your Google Drive or OneDrive accounts for quick access to your resources.
65, 75, and 86 inch screens with crystal clear display that leverage HDMI 2.0 and USB-C technology.
Easily and seamlessly annotate over any content displayed on your Promethean ActivPanel screen.
Connect laptops and other computers to the panel and interact with content directly from the panel screen.
Learn More about Plug and Play ConnectivityPromethean For Education
Transformation in sharing of knowledge, fueled by the impact of technology in the teaching and learning process.
Interactive
Provides teaching software engineered to drive student engagement.
With Teaching Tools
Work seamlessly with educational platforms like Google Classroom and Microsoft Teams
Intuitive Remote
Navigate your panel with an intuitive remote so you can move around the classroom freely
Promethean For Corporate
Enhance collaboration during meetings with Interactive Whiteboard Panel
Ideal for Brainstorming
Ideate concepts visually and improve team collaboration.
Work Seamlessly
Let employees look over, edit, and create documents and presentations in real-time.
Heightened Collaboration
Extend meetings to outside parties such as your clients and improve satisfaction.
We Offer Promethean Training
Discover the power of Promethean! We offer FREE and exclusive Training Courses, designed to equip you with the knowledge and skills needed to master the Promethean platform.
Specifications
| FEATURES | ACTIVPANEL 9 STANDARD | ACTIVPANEL 9 PREMIUM |
|---|---|---|
| DISPLAY | ||
| Available Sizes | 65″ 4K, 75″ 4K, 86″ 4K | 65″ 4K, 75″ 4K, 86″ 4K |
| Screen Type | TFT LCD (Direct LED Backlight) | TFT LCD (Direct LED Backlight) |
| Blue Light Reduction | Yes | Yes |
| Bonded Glass | Yes | Yes |
| Aspect Ratio | 16:9 | 16:9 |
| Display Area | 65″ 4K: 1429 x 804 mm (56.3 x 31.7 in) 75″ 4K: 1652 x 930 mm (65 x 36.6 in) 86″ 4K: 1895 x 1066 mm (74.6 x 41.9 in) | 65″ 4K: 1429 x 804 mm (56 3 x 31.7 in) 75″ 4K: 1652 x 930 mm (65 x 36.6 in) 86″ 4K: 1895 x 1066 mm (74.6 x 41.9 in) |
| LCD Viewing Angle | 178° | 178° |
| LCD Response Time | 8 ms | 8 ms |
| LCD Refresh Rate (Panel) | 60 Hz | 60 Hz |
| LED Lifespan | 50,000 hours | 50,000 hours |
| Contrast Ratio | 5000:1 Dynamic 1200:1 Static | 5000:1 Dynamic 1200:1 Static |
| Brightness | 400 cd/m2 | 400 cd/m2 |
| Ambient Light Sensor | Yes | Yes |
| Glass Hardness | 9H (pencil), 7 (Mohs) | 9H (pencil), 7 (Mohs) |
| Glass Type | Heat tempered, Anti-Glare | Heat tempered, Anti-Glare |
| INTERACTIVITY | ||
| Vellum Touch Technology | Yes | Yes |
| Continuous Touch Points | 20 | 20 |
| Touch Resolution | 32768 X 32768 px | 32768 X 32768 px |
| Response Time | 10 ms | s5 ms |
| Touch Accuracy | 1 mm | 1 mm |
| Tracking Rate | 4m/s | 4m/s |
| Scan Rate | 200 Hz | 200 Hz |
| Gestures and Edge Swipes | Windows• supported | Windows• supported |
| Eraser Included (Block Eraser) | No | Yes |
| Unique Pen IDs | 1 | 2 |
| Pen and Touch Differentiation | Yes | Yes |
| Palm Erase | Yes | Yes |
| Palm Rejection | Yes | Yes, writing and non-writing hand |
| Pens Included | Yes, 2 | Yes, 4 |
| Pen Type | Battery-less pen | Battery-less pen |
| Pen Holder | Integrated full-length pen tray | Integrated full-length pen tray |
| Pen Tip Diameter | 3mm | 3 mm (Eraser 7 mm) |
| Classroom Essential Apps | Including Whiteboard, Annotate, Timer, Spinner, Screen Capture, Screen Share, Browser, PDF Reader, Media Player, Screen Recorder | Including Whiteboard, Annotate, Timer, Spinner, Screen Capture, Screen Share, Browser, PDF Reader, Media Player, Screen Recorder |
| Compatibility | Windows• 7 to 11; Mac os• 10.8 to 10.11; macos• Sierra 10.12.1 or later; Linux• Ubuntu 20.04 LTS; Chrome OS™ | Windows® 7 to 71; Mac os• 70.8 to 10.11; macOS® Sierra 10.12.1 or later; Linux® Ubuntu 20.04 LTS; Chrome OS'” |
| COMPUTING | ||
| Operating System | ActivPanel OS | ActivPanel OS |
| RAM | 4 GB | 6.5 GB |
| Internal Storage | 32 GB | 64GB |
| CPU | ARM CORTEX-A73 x 4 | ARM CORTEX-A73 x 4 |
| GPU | ARM CORTEX-A73 x 4 | ARM CORTEX-A73 x 4 |
| ActivSynC” | No | Yes |
| Trusted Platform Module | Yes | Yes |
| Cloud Based User Profiles | Yes | Yes |
| AUDIO | ||
| Dual Front-facing Speakers | 2x 15W | 2x 18W |
| Subwoofer | No | 1 X 15W |
| Microphone Array | No | Yes |
| CONNECTIVITY | ||
| OPS Slot | 1 | 1 |
| HDMI In (Rear) | 2(2.0) | 2 (1 X 2.0, 1 X 2.1) |
| HDMI In (Front) | 1 (2.0) | 1 (2.0) |
| Display Port | 1 (1.2) | 1 (1.2) |
| USB-A 2.0 (Rear) | 1 | 1 |
| USB-C 3.2 (Rear) | 1 (60 W Power Delivery) | 1 (100 W Power Delivery) |
| USB-B 3.0 (Touch, Front) | 1 | 1 |
| USB-B 3.0 (Touch, Rear) | 3 | 3 |
| USB-A 3.0 (Front) | 2 | 2 |
| USB-A 3.0 (Rear) | 2 | 2 |
| MicroSD Slot | Yes | Yes |
| LAN In (RJ45) | 1 Gbps | 1 Gbps |
| LAN Out (RJ45) | 1 Gbps | 1 Gbps |
| Wake-on-LAN | Yes | Yes |
| Wi-Fi (Client) | IEEE 802.11 a/b/g/n/ac/ax, Wi-Fi 6 and dual band supported | IEEE 802.11 a/b/g/n/ac/ax, Wi-Fi 6 and dual band supported |
| Bluetooth | 5.0 | 5.0 |
| HDMI Out | 1 (2.0) | 1 (2.0) |
| VGA In | 0 | 1 |
| PC Audio (3.5 mm) | 0 | 1 |
| AV-In (3.5 mm) | 1 | 1 |
| Mic(3.5 mm) | 1 | 1 |
| Audio Out (3.5 mm) | 1 | 1 |
| RS-232 | 1 | 1 |
| Proximity Sensor for Warm Boot | No | Yes |
| NFC (Near-field Communication) | No | Yes |
| DOWNLOAD FULL SPECIFICATION DATASHEET | DOWNLOAD FULL SPECIFICATION DATASHEET | |
| DISPLAY | |
| Screen Size and Resolution | 65″ 4K (3840 x 2160 @ 60 Hz) 75″ 4K (3840 x 2160 @ 60 Hz) 86″ 4K (3840 x 2160 @ 60 Hz) |
| Screen Type | TFT LCD (Direct LED Backlight) |
| Blue Light Reduction | Yes |
| Aspect Ratio | 16:9 |
| Display Area | 65″: 1431 x 805 mm (56.3 x 31.7 in) 75″: 1652 x 930 mm (65 x 36.6 in) 86″: 1897 x 1068 mm (74.7 x 42 in) |
| Display Colors | 1.07 Billion (10-bit) |
| LCD Viewing Angle | 178° |
| LCD Response Time | 8 ms |
| LCD Refresh Rate (Panel) | 60 Hz |
| LED Lifespan | 50,000 hours |
| Contrast Ratio | 5000:1 Dynamic 1200:1 Static |
| Brightness | 350 cd/m2 |
| Ambient Light Sensor | Yes |
| Glass Hardness | 8H (pencil), 7 (Mohs) |
| Glass Type | Heat tempered, Anti-Glare |
| Glass Thickness | 3.2 mm |
| INTERACTIVITY | |
| Vellum Touch Technology | Yes |
| Continuous Touch Points | 20 |
| Touch Resolution | 32768 x 32768 px |
| Response Time | 10 ms |
| Touch Accuracy | 1 mm |
| Tracking Rate | 4 m/s |
| Scan Rate | 200 Hz |
| Gestures and Edge Swipes | Windows® supported |
| Unique Pen IDs | 1 |
| Pen and Touch Differentiation | Yes |
| Palm Erase | Yes |
| Palm Rejection | Yes |
| Pens Included | Yes, 2 |
| Pen Type | Battery-less pen |
| Pen Holder | Integrated full-length pen tray |
| Pen Tip Diameter | 3 mm |
| Compatibility | Windows® 7 to 11; Mac OS® 10.8 to 10.11; macOS® Sierra 10.21.1 or later; Linux® Ubuntu 20.04 LTS; Chrome OS™️ |
| AUDIO | |
| Dual Front-facing Speakers | 2 x 10 W |
| COMPUTING | |
| Operating System | No OS |
| CONNECTIVITY | |
| OPS Slot | 1 |
| HDMI 2.0 (Front) | 1 |
| HDMI 2.0 (Rear) | 2 |
| USB-A 2.0 (Front) | 1 |
| USB-A 2.0 (Rear) | 2 |
| USB-B 2.0 Touch (Front) | 1 |
| USB-B 2.0 Touch (Rear) | 2 |
| USB-C 2.0 15 W Power Delivery (Front) 1 | 1 |
| LAN In (10/100/1000) | 1 |
| LAN Out (10/100/1000) | 1 |
| VGA | 1 |
| Wake-on-LAN | Yes |
| Audio In (3.5 mm) | 1 |
| Audio Out (3.5 mm) | 1 |
| RS232 | 1 |
| FEATURES | ACTIVINSPIRE | CLASSFLOW |
|---|---|---|
| ACCESSIBILITY | ||
| Available Offline | Yes | Y (ClassFlow Desktop) |
| Available Online | No | Yes |
| PRESENTATION TOOLS FOR STUDENT ENGAGEMENT | ||
| Send Text-based Content to Student Devices | Yes | Yes |
| Send Media-rich Content to Student Devices | No | Yes |
| Send Students’ Work to Display from Teacher’s Mobile Device | No | Yes |
| Instant Polling | Yes | Yes |
| Assessment in Class | Yes | Yes |
| Assessment at Home | No | Yes |
| Instant Whiteboard | Yes | Yes |
| Annotation | Yes | Yes |
| Handwriting Recognition | Yes | Yes (ClassFlow Desktop) |
| Display Multiple Lesson Pages Simultaneously | No | Yes |
| Supports Multi-touch | Yes | Yes |
| Math Tools | Yes | Yes |
| Translucency Slider | Yes | No |
| RESOURCES | ||
| Unlimited Cloud Storage | No | Yes |
| Integration with Cloud Service (Dropbox, Google Drive, OneDrive) | No | Yes |
| Importing Flipcharts | NA | Yes |
| Importing PowerPoint, PDF, Smart Notebook | Yes | Yes |
| Lesson Repository | Yes | Yes |
| Sell/Buy Original Lessons | No | Yes |
| DATA COLLECTION TOOLS | ||
| Saving & Sharing of Instant Whiteboard | Yes | Yes |
| Polling Results | Yes | Yes |
| Assessment Results | Yes | Yes |
| Exporting Results to Excel | Yes | Yes |
| TEACHER MANAGEMENT TOOLS | ||
| Student Grouping within Classes | No | Yes |
| Remote Control of Lessons | No | Yes |
| Teacher Lock for Lessons | Yes | No |
| Student Badging | No | Yes |
| Class Web Page | No | Yes |
| Teacher Posts | No | Yes |
| STUDENT MANAGEMENT TOOLS | ||
| Student Login | No | Yes |
| Assignments | No | Yes |
| Digital Notebooks | No | Yes |
| Badges | No | Yes |
| Unlimited Cloud Storage | No | Yes |
